Folding Container Parameters
|
Supporting equipment:
|
Parameters: |
| Wall: Thermal insulation rock wool color steel composite sandwich panel. |
Roof bearing: 50 Kg/m²
Floor bearing capacity: 150 kg/m²
|
| Floor: Adopt A-glass Fire-proof board. |
Walkway bearing capacity: 200 kg/m².
Wall side pressure: 80 kg/ m².
|
|
Windows: The window adopts push-pull series made of aluminum alloy for anti-theft.
|
Wall deformation coefficient: 300 kg/ m²
|
| Security door: Anti-theft Steel door is to be used. |
Fire resistance rating: Grade A fire resistance,
|
| Electrical system: circuit protector, five-hole socket, LED lamp, air conditioning socket, light switch. |
Anti Earthquake: 10 Grade.
|
| Top: 104 type color steel tile is used for the outer top, and 831 type ceiling tile is used for the inner top. |
Anti- wind resistance rating: 11 wind resistance rating
|
Product Details
| Classification |
Heading |
Specification |
| Size |
Length |
5800mm |
| |
Width |
2500mm |
| |
Height |
2450mm |
| Steel Structure |
Pillar |
Galvanized pipe |
| |
Beams |
Galvanized pipe |
| Board |
Roof |
14.5㎡ thermal insulation rock wool |
| |
Wall |
50mm thermal insulation rock wool color steel plate |
| |
Ground |
15mm A-class fire-resistant cloth board |
| Accessories |
Window |
950mm*1200mm aluminum alloy anti-theft integrated |
| |
Door |
860mm*1980mm special anti-theft door for folding box |
| Paint |
Integral frame protective coating |
Carpoly High Gloss Enamel |
Characteristical
- Fast installation speed (3-5 minutes for completing the installation).
- The whole steel structure is made of Q235B galvanized material
- The whole wallboard adopts thermal insulation rock wool color steel
- The window adopts push-pull series made of aluminum alloy for anti-theft.
- The cabinet floor is made of 15mm glass magnesium plate for fireproof and moisture-proof.
- The post-holding height is only 44CM.
- The roof is also covered with grade a fireproof rock wool.
Advatage
Shipping and Export
Our product only has 42cm height after folding, and we save more than 80% of the transportation. The 40 foot container can hold 10 sets of folding container house. Compared with other box room outlets, it can save more transportation costs and high manual installation costs. Meet the quality inspection conditions of all customs, install quickly on site, use repeatedly for many times, and have a service life of more than 15 years, which is recognized and favored by international friends around the world.
Storage
Our container room can store more than 10 sets, which greatly saves the storage area and the site use cost.
Technical Details
FAQ
Q. What information should we offer before you quote?
A. 1.you have the drawing, please give us and tell us the material you use.
2. If no drawing, please tell us the usage and the size of the house, then we design for you with the good price.
Q. What's the application?
A. the container can be used to container office, container house,prefabricated house, hotel, clinic, dormitory, camp,toilet,bathroom, bedroom, canteen, shop, shower room, storage room, hospital and so on.
Q: In the face of 3 million volts of lightning, is a metal house like a container safe?
A: Regarding thunderstorms in closed metal spaces, according to Mike Faraday’s theory: Metal box-shaped buildings are the safest place. Electric charges will flow evenly around the closed metal container without passing through the container. The principle Similar to being on an airplane.
Q: How much is the price of the folding container? Is there a discount for bulk purchase?
A: Please contact us for specific information, we will have someone to answer:
